LIB - TIA - DO MULTIPLE RESET BLOCK

  • Price: €5.00

Our Services

Download Request

Flexible Single, Dual and Triple Output Management

The A4U General Digital Output Control Blocks provide a standardized and reusable solution for managing single, dual and multiple digital outputs within PLC-based industrial automation systems. Designed as master control blocks, they provide a structured method for controlling output activation and reset behaviour through command signals, permissives and general permissive conditions, helping engineers maintain consistent logic across different machines and process applications. The Single Digital Output General Reset block manages one retentive output, allowing the output to remain active after a valid Turn On command until a Turn Off command is received with the required permissive conditions. The Dual Digital Output General Reset block manages two outputs and allows a general reset condition to switch off both outputs without waiting for the remaining individual permissive conditions, providing coordinated control where multiple outputs must respond to a common reset command. Additional General Set variants extend the same structured approach to multiple outputs, including dual and triple-output configurations, allowing individual commands and permissives to control coordinated output states according to the process requirement. Because these are standard master blocks, they are not dependent on a particular SCADA system and can be integrated with different HMI or SCADA platforms according to the project design. The blocks provide a reusable foundation for command handling, permissive management and digital output coordination, helping reduce repeated PLC engineering and maintain a consistent control philosophy across industrial automation projects.

A4U General Digital Output Control Blocks - Flexible Control for Multiple Digital Outputs

Standardize digital output control with the A4U General Digital Output Control Blocks. Designed as reusable master blocks for single, dual and multiple-output applications, the solution combines command handling, permissive evaluation and coordinated set or reset behaviour within a consistent PLC control structure. Independent of any specific SCADA platform, these blocks can be integrated into different HMI and SCADA architectures, providing a flexible foundation for reliable digital output management across industrial automation projects.

FAQs

What are the A4U Digital Output General Reset Control Blocks?
+
The A4U Digital Output General Reset Control Blocks are standardized PLC master blocks designed to control and reset one or multiple digital outputs in a structured way. They are available for Single, Dual and Triple output applications, allowing engineers to select the appropriate block according to the required number of controlled outputs.
What is the difference between the Single, Dual and Triple Output versions?
+
The main difference is the number of digital outputs managed by the block. The Single Output version manages one output, while the Dual and Triple versions are intended for applications where two or three related outputs must be controlled within the same standardized logic structure.
How does the General Reset function work?
+
The General Reset function provides a common condition that can reset or switch off the controlled output or outputs according to the configured block logic. Individual output commands and permissive conditions are also evaluated as part of the control operation. The manual specifically describes the single-output block as maintaining its output until the appropriate OFF command and permissive conditions are satisfied.
Do the blocks support permissive conditions?
+
Yes. Permissive signals are part of the block structure and are used to determine whether the corresponding output operation can be executed. In the documented versions, dedicated permissive inputs are provided for the controlled outputs.
Are the output behaviors identical for all versions?
+
Not necessarily. The behavior depends on the selected block configuration. For example, the documented Single General Reset block uses a retentive output behavior, while the documented two-output General Reset version is described as non-retentive and keeps the outputs active while the relevant command and permissive conditions are present.
